Power (50HZ):30KW-800KW
功率(50Hz): 30KW-800KW
110V, 220V, 380V, 400V, 415V, 440V, 480V, 660V, 690V are obtainable;
110V, 220V, 380V, 400V, 415V, 440V, 480V, 660V, 690V可选；
Electrical start, spring start and air start are optional;
电启动，弹簧启动，空气启动可选；
Engine monitor panel and Genset control panel are optional;
柴油机监控仪，发电机组控制屏可选；
Powered by Yuchai engine coupled with Marathon; Stamford, Siemens, Liandian, Sanbo alternators are optional;
玉柴配三波；斯坦福，西门子，兰电电机可选；
IMO TierⅡCertificate；
柴油机国际防止空气污染证书（第Ⅱ阶段排放证书）可供；
CCS approved；
可提供CCS船检
Genset
船用柴油发电机组参数 |
Engine
柴油机参数 |
Alternator
发电机参数 |
Unit
机组外形 |
Order No.
订单号 |
Model
机组型号 |
Prime Power
额定功率
(KW/KVA) |
Model
型号 |
Continuous
Power
持续功率
(KW) |
Cyl.
缸数 |
Fuel Consumption
燃油消耗率
(L/H) |
Sanbo
三波
(Option/可选) |
Dimension
尺寸
L*W*H(mm) |
Weight
重量
（kgs） |
SYM30 |
CCFJ30 |
30/38 |
YC4108C |
40 |
4 |
≤200 |
SB-HW4(.D)-30 |
1780*715*1035 |
750 |
SYM40 |
CCFJ40 |
40/50 |
YC4108ZC |
50 |
4 |
≤200 |
SB-HW4(.D)-40 |
1850*715*1035 |
750 |
SYM50 |
CCFJ50 |
50/63 |
YC6108CA |
63 |
6 |
≤189 |
SB-HW4(.D)-50 |
1900*860*1000 |
1300 |
JHYM75 |
CCFJ75 |
75/94 |
YC6108ZLCA |
90 |
6 |
≤189 |
SB-HW4(.D)-75 |
2300*860*1000 |
1330 |
JHYM90 |
CCFJ90 |
90/113 |
YC6108ZLCB |
112 |
6 |
≤189 |
SB-HW4(.D)-90 |
2600*930*1160 |
1400 |
JHYM100 |
CCFJ100 |
100/125 |
YC6A170C |
125 |
6 |
≤189 |
SB-HW4(.D)-100 |
2600*930*1160 |
1950 |
JHYM150 |
CCFJ150 |
150/188 |
YC6M240C |
176 |
6 |
≤189 |
SB-HW4(.D)-150 |
2900*1020*1420 |
2000 |
JHYM70 |
CCFJ170 |
170/212 |
YC6M260C |
192 |
6 |
≤189 |
SB-HW4(.D)-180 |
2900*1020*1420 |
2100 |
JHYM180 |
CCFJ180 |
180/225 |
YC6M300C |
219 |
6 |
≤189 |
SB-HW4(.D)-180 |
2950*1020*1420 |
2300 |
JHYM200 |
CCFJ200 |
200/250 |
YC6MK330C |
242 |
6 |
≤189 |
SB-HW4(.D)-200 |
2950*1020*1420 |
2950 |
JHYM250 |
CCFJ250 |
250/313 |
YC6T400C |
294 |
6 |
≤192 |
SB-HW4(.D)-250 |
3000*1030*1750 |
3200 |
JHYM300 |
CCFJ300 |
300/375 |
YC6T450C |
330 |
6 |
≤192 |
SB-HW4(.D)-300 |
3200*1030*1750 |
4100 |
JHYM320 |
CCFJ320 |
320/400 |
YC6T490C |
360 |
6 |
≤195 |
SB-HW4(.D)-320 |
3500*1050*1750 |
4300 |
JHYM420 |
CCFJ420 |
420/525 |
YC6C650L-C20 |
478 |
6 |
≤195 |
SB-HW4(.D)-456 |
3800*1050*1750 |
7200 |
JHYM450 |
CCFJ450 |
450/562 |
YC6C700-C20 |
515 |
6 |
≤195 |
SB-HW4(.D)-456 |
3810*1350*1850 |
7500 |
JHYM500 |
CCFJ500 |
500/625 |
YC6C820L-C21 |
600 |
6 |
≤195 |
SB-HW4(.D)-500 |
4100*1450*1890 |
8100 |
JHYM600 |
CCFJ600 |
600/750 |
YC6CL960L-C20 |
706 |
6 |
≤195 |
SB-HW4-600-6P |
4200*1450*1890 |
8300 |
JHYM650 |
CCFJ650 |
650/813 |
YC6CL1035L-C20 |
760 |
6 |
≤195 |
SB-HW4-700-6P |
4500*1550*1900 |
8500 |
JHYM800 |
CCFJ800 |
800/1000 |
YC6CL1200-C20 |
882 |
6 |
≤195 |
SB-HW4-1000-6P |
4675*1450*1940 |
8900 |
|
